Indian Bullet Spares Catalogue

Timing

Timing Gears - Timing Cover

Please Note: When ordering parts please quote: Part No. and number required, model, year and country type (Royal Enfield exports the following main country types: Indian, European and USA/Canada).

Differences between models are indicated.

Once you have decided on your requirements email us.

Timing Gears

Key No. Part No. Description Qty. Bullet Bu. Mach 350 Bu. 500 Lightning T'bird Remarks
350 Dlx Mac Cam Elec 500 535 535ES
1 141815 Timing pinion, Standard (2 dots) 1
140115 Timing pinion, U/S (1 dots) 1
141816 Timing pinion, O/S (3 dots) 1
2   Worm Nut 1
  Worm Nut 1     Without rubber plug
  Worm Nut 1
3 141818 Cam assy, Exhaust 1
500429 Cam assy, Exhaust 1
4 141817 Cam assy, Inlet 1
500428 Cam assy, Inlet 1
5 140599 Bush, Short - cam wheel 6
6 140120 Idler pinion assy 2
7 140121 Thrust washer, Idler pinion 4
8 140606 Bush, Idler pinion 2
9 140165 Pinion, Distributor 1
10 140166 Nut, Pinion 1
11 112078 Shim, Cam play AR

[top]

Timing Cover

Key No. Part No. Description Qty. Bullet Bu. Mach 350 Bu. 500 Lightning T'bird Remarks
350 Dlx Mac Cam Elec 500 535 535ES
A1 140779 Timing cover assy (Inches) 1         Before July 2002
145050/B Timing cover assy (Metric) 1         After July 2002
597107 Timing cover assy (Old oil circuit) 1                     Before July 2002
597109 Timing cover assy (New oil circuit) 1                   For March, After July 2002
805001 Timing cover assy 1
A2 112147 Oil pump kit 1
597066 Oil pump kit 1
597261 Oil pump kit 1
1 142123 Timing cover (Inches) 1     Before July 2002
145047/B Timing cover (Metric) 1     After July 2002
500416 Timing cover (Old oil circuit) 1                     Before July 2002
500159/A Timing cover (New oil circuit) 1                   After July 2002
2 144047 Gasket, Timing Cover 1     Before Nov 2000
144617 Gasket, Timing Cover 1     After Nov 2000
500414 Gasket, Timing Cover 1
3 140038 Oil feed plug (Inches) 1     Before July 2002
145020/C Oil feed plug (Metric) 1     After July 2002
4 144844 Washer, Copper - oil feed plug 1
5 144841 Screw, long (Inches) 4 Before July 2002
145061/C Slotted Head Screw, Long (Metric) 4 After July 2002
6 140771 Washer fibre - Timing cover 10
7 144638 Screw, Short (Inches) 6 Before July 2002
145022/C Screw, Short (Metric) 6 After July 2002
8 144613 Stud - Oil filter (Inches) 1     Before July 2002
145025/C Stud - Oil filter (Metric) 1     After July 2002
500614 Stud - Oil filter 1
9 500621 O' Ring - Oil filter stud 2
10 140029 Oil filter element 1
500613 Oil filter element 1
11 144614 Cup - Oil filter element 1
12 144615 Felt Washer - Oil filter stud 1
13 500617 Washer - Oil filter 1
14 144716 Spring - Oil filter 1
500637 Spring - Oil filter 1
15 500619 'O' ring 1
16 500618 Cap - Oil filter 1
17 144600 Fibre Washer 1
18 140293 Washer plain 1
19 145233 Dome nut, M8 1
500633 Dome nut, M8 1
20 140041 Disc - Feed pump 1
144131 Disc - Feed pump 1
21 140043 Plunger - Feed pump 1
144130 Plunger - Feed pump 1
22 140040 Oil pump spindle 1
23 140044 Plunger - Return Pump 1
144132 Plunger - Return Pump 1
24 140042 Disc - Return Pump 1
144133 Disc - Return Pump 1
25 140045 Spring - oil pump 2     Before Oct 1996
144134 Spring - oil pump 2     After Oct 1996
26 140049 Pad - oil pump 2
27 144616 Gasket - Cover oil pump 2
28 140046 Cover plate - oil pump 2
29 145232 Socket Head screw M5 8
30 500616 Spring cap 1
31 500635 Key oil pump shaft 2
32 500600 Oil pump drive shaft 1
33 500608 Spindle, Driven gear scavenge pump 1
34 500605 Driven Gear, Scavenge pump 1
35 500606 Drive Gear, Scavenge pump 1
36 500612 'O' ring - Oil pump 2
37 500630 Cover, Scavenge pump 1
38 500632 Screw 8
39 500601 Drive Gear, Feed pump 1
40 500602 Driven Gear, Feed pump 1
41 500604 Spindle, Driven Gear Feed pump 1
42 500629 Cover, Feed pump 1
43 500622 Oil seal 1
44 143496 Fibre Washer 3
